Castle Avon 1 Speakers
AVON 1
With breakthrough Twin Drive Transmission Line technology, combined with real wood veneers, hand crafted and polished to perfection - Castle Avon is a delight to both eyes and ears.
Determined to both perfect and take advantage of the Transmission Line speaker principles, Castle engineers embarked on a three year investigation into the acoustics, mathematics and all performance aspects of such loudspeakers. The result was a break through in TL Theory. In its simplest explanation, driving the line at two distinct points overcomes both the damping problem and loss of energy, resulting in a smooth power response from the lowest fundamentals right through to the midrange frequencies.
Avon’s ribbon tweeter design uses an ultra-thin alloy sandwich precisely positioned in a powerful transverse magnetic field, where the ribbon acts as both the voice coil and diaphragm. In this way the whole radiating area is driven directly and responds accurately to the music signal without energy storage or breakup. Together, the direct drive and low mass of the ribbon provide superb musical detailing and transient attack, resolving the harmonic content of the music in a thrilling and natural way.
Â
Specifications
| Discription | 2-way bookshelf speaker |
| Enclosure type | SDEL – Single Drive Extended Line |
| Bass Driver | 130mm Woven Carbon Fibre Woofer |
| Treble Driver | 12 x 45 mm True Ribbon |
| Sensitivity | 87dB |
| Recommended Amp. Power | 25-100W |
| Peak SPL | 95dB |
| Compatible | 8Ω |
| Minimum Impedance | 4.3Ω |
| Frequency Response | 60Hz ~ 20kHz |
| Bass Extension | 55Hz |
| Dimensions (WxDxH) | 320 x 180 x 230mm |
| Net Weight | 5.8kg each |
